Y2-10 Red/Black Photovoltaic Branch Connector

Y2-10 Red/Black Photovoltaic Branch Connector

Key Features

  • Two-way PV branch connector
  • All-black professional finish
  • Rated up to 1000V DC
  • 30A maximum current
  • Low contact resistance
  • IP68 waterproof and dustproof
  • PPO insulated housing
  • V-0 flame-retardant construction

Applications

  • Two-string PV branch connections
  • Residential solar systems
  • Commercial rooftop installations
  • Solar combiner systems
Category:

Colour-Coded Two-Way PV Connector

The BritiPower Y2-10 Red/Black Branch Connector features colour-coded polarity identification, allowing for faster installation and reduced wiring errors while delivering reliable performance in photovoltaic systems.

  • Two-way PV branch connector
  • All-black professional finish
  • Rated up to 1000V DC
  • 30A maximum current
  • Low contact resistance
  • IP68 waterproof and dustproof
  • PPO insulated housing
  • V-0 flame-retardant construction
  • Two-string PV branch connections
  • Residential solar systems
  • Commercial rooftop installations
  • Solar combiner systems
Specification Value
Model Y2-10 Red/Black
Rated Voltage 1000V DC
Maximum Current 30A
Contact Resistance ≤5mΩ
Protection Rating IP68
Protection Class Class II
Operating Temperature -40°C to +85°C
Insulation Material PPO
Fire Rating V-0
Application Class Class A

PDFDownload Data Sheet
